Attaching cables
Make sure to match the following:
• The USB symbol on the cable with the USB symbol on the printer
• The appropriate Ethernet cable to the Ethernet port
Use the To
1 Rear USB port Attach a keyboard to the printer.
2 USB printer port Connect the printer to a computer.
3 Ethernet port Connect the printer to a network.
4 USB wireless port Attach an optional wireless network adapter.
5 Security lock port Lock the system controller board.
6 Printer power cord socket Connect the printer to a properly grounded electrical outlet.
Networking
Notes:
• Purchase a wireless network adapter before setting up the printer on a wireless network. For more information,
contact the place where you purchased the printer.
• A Service Set Identifier (SSID) is a name assigned to a wireless network. Wired Equivalent Privacy (WEP), Wi-Fi
Protected Access (WPA), WPA2, and 802.1X - RADIUS are types of security used on a network.
Preparing to set up the printer on an Ethernet network
To configure your printer to connect to an Ethernet network, organize the following information before you begin:
Additional printer setup 33
