2-2. Outdoor Unit (60Hz model: MMY-MUP***1HT7(J)P)
No Name Model Specification
MMY-MUP0801HT7(J)P MMY-MUP1001HT7(J)P MMY-MUP1201HT7(J)P MMY-MUP1401HT7(J)P
MMY-MUP14A1HT7(J)P
MMY-MUP1601HT7(J)P MMY-MUP1801HT7(J)P MMY-MUP2001HT7(J)P MMY-MUP2201HT7(J)P MMY-MUP2401HT7(J)P
1 Compressor LA771A3TB-20M
Output:4.0kW×1 ○
1 Compressor LA771A3TB-20M
Output:5.8kW×1 ○
1 Compressor LA771A3TB-20M
Output:7.3kW×1 ○
1 Compressor LA771A3TB-20M
Output:10.0kW×1 ○
1 Compressor LA1201K4FB-10UC
Output:8.0kW×1 ○
1 Compressor LA1201K4FB-10UC
Output:9.7kW×1 ○
1 Compressor LA1201K4FB-10UC
Output:11.5kW×1 ○
1 Compressor LA1201K4FB-10UC
Output:13.0kW×1 ○
1 Compressor LA771A3TB-20M
Output:7.9kW×2 ○
1 Compressor LA771A3TB-20M
Output:9.5kW×2 ○
2 4-way valve coil SHF AC208-230V 60Hz
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
AC208-230V 60Hz
SV3D, SV41, SV42
AC208-230V 60Hz
SV3F
4 Pulse motor valve coil PAM PMV1
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
4 Pulse motor valve coil HAM PMV2, 3
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
4 Pulse motor valve coil UKV PMV4
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
5 High-pressure SW ACB-4UB237W OFF:4.15MPa ON:3.2MPa
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
6 Pressure sensor(For high pressure) NSK-BH038F-823 0.5~4.5V/0~3.92MPa
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
7 Pressure sensor(For low pressure) NSK-BH020F-822 0.5~3.5V/0~2.0MPa
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
8 Fan motor ICF-620A1000-1 DC530 - 620
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
9 Case heater(For comp.) — AC240V/29W
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
3 2-way valve coil FDF
○ ○
3 2-way valve coil TEV
○ ○
○
○○ ○ ○ ○ ○ ○
○ ○ ○ ○ ○○ ○
○
- 20 -
