2-3. Outdoor Unit (50Hz model: MMY-MUP***1HT8P-A)
No Nam
e Model Specification
MMY-MUP0801HT8P-A MMY-MUP1001HT8P-A MMY-MUP1201HT8P-A MMY-MUP1401HT8P-A
MMY-MUP14A1HT8P-A
MMY-MUP1601HT8P-A MMY-MUP1801HT8P-A MMY-MUP2001HT8P-A MMY-MUP2201HT8P-A MMY-MUP2401HT8P-A
1 Compressor LA771A3TB-20M
Output:4.4kW×1 ○
1 Compressor LA771A3TB-20M
Output:6.5kW×1 ○
1 Compressor LA771A3TB-20M
Output:8.1kW×1 ○
1 Compressor LA771A3TB-20M
Output:10.9kW×1 ○
1 Compressor LA1201K4FB-10UC
Output:9.3kW×1 ○
1 Compressor LA1201K4FB-10UC
Output:11.4kW×1 ○
1 Compressor LA1201K4FB-10UC
Output:13.2kW×1 ○
1 Compressor LA1201K4FB-10UC
Output:14.9kW×1 ○
1 Compressor LA771A3TB-20M
Output:9.0kW×2 ○
1 Compressor LA771A3TB-20M
Output:10.7kW×2 ○
2 4-way valve coil SHF AC220-240V 50Hz
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
AC220-240V 50Hz
SV3D, SV41, SV42
AC220-240V 50Hz
SV3F
4 Pulse motor valve coil PAM PMV1
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
4 Pulse motor valve coil HAM PMV2, 3
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
4 Pulse motor valve coil UKV PMV4
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
5 High-pressure SW ACB-4UB237W OFF:4.15MPa ON:3.2MPa
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
6 Pressure sensor(For high pressure) NSK-BH038F-823 0.5~4.5V/0~3.92MPa
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
7 Pressure sensor(For low pressure) NSK-BH020F-822 0.5~3.5V/0~2.0MPa
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
8 Fan motor ICF-620A1000-1 DC530 - 620
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
9 Case heater(For comp.) — AC240V/29W
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
○ ○ ○ ○
○○ ○ ○
3 2-way valve coil TEV
○ ○ ○ ○ ○ ○
○ ○ ○○
3 2-way valve coil FDF
○ ○
- 21 -
