Toshiba Satellite L640 User Manual

Chapter 4 Replacement Procedures
4.3 HDD/SSD
Removing a HDD/SSD-H9.5mm
The following describes the procedure for removing the HDD/SSD (See Figure 4-3-1 to 4-3-
3).
CAUTION: Take care not to press on the top or bottom of a HDD/SSD. Pressure may
cause data loss or damage to the device.
1. Turn the computer upside down.
2. Remove the following screws securing a HDD/SSD slot cover
M2.04.0B BIND screw x2
3. Remove the following screws securing the HDD/SSD assembly.
 M3.03.0B FLAT BIND screw x2
4. Disconnect the HDD/SSD assembly from the connector on the mother board.
MAIN HDD OR SSD
Figure 4-3-1 Turn the computer upside down
Satellite L640/L645, Satellite Pro L640/Pro L645 Maintenance Manual (960-Q08)

Toshiba Satellite L640 Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	802.11b/g/n
Webcam	Integrated Webcam
Processor	Intel Core i3/i5
RAM	Up to 8GB DDR3
Storage	320GB HDD
Display	14-inch HD
Graphics	Intel HD Graphics
Operating System	Windows 7 Home Premium
LAN	10/100 Ethernet
Battery	6-cell Lithium Ion
Ports	HDMI, VGA, RJ-45, Microphone input, Headphone output
