Board Layout
B.3 TP ON-OFF Board
<Front layout>
SW1
Figure B-3-1 TP ON-OFF Board layout (Front)
NUM Location Function
(01) SW1 TP ON-OFF Switch
Table B-3-2 TP ON-OFF Board switch
<Back layout>
CN1
Figure B-3-3 TP ON-OFF Board layout (Back)
NUM Location Function
(01) CN1 TP ON-OFF Board to Touch Pad Board CONN
Table B-3-4 Finger Print Board connectors
Satellite L600/L640/L645, Satellite Pro L600/Pro L640/Pro L645 Maintenance Manual (960-Q08)
