Chapter 4 Replacement Procedures
4.10 Touch Pad
Removing the touch pad
The following describes the procedure for removing the touch pad (See Figure 4-10-1 to 4-
10-3).
1. Peel off the glass tape and disconnect the touch pad cable, touch pad board cable
from the connector on the touch pad.
2. Remove the following screws securing the Touch pad plate.
 M2-0.4x2 SUPER THIN HEAD screw x2
 M2.0x3.0 SUPER THIN HEAD screw x4
3. Remove the touch pad board and touch pad plate and touch pad lock.
4. Peel off and remove the touch pad from the Top cover assembly.
Figure 4-10-1 Remove the touch pad FFC cable
Satellite L640/L645, Satellite Pro L640/Pro L645 Maintenance Manual (960-Q08)
4-36

Toshiba Satellite L640 Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	802.11b/g/n
Webcam	Integrated Webcam
Processor	Intel Core i3/i5
RAM	Up to 8GB DDR3
Storage	320GB HDD
Display	14-inch HD
Graphics	Intel HD Graphics
Operating System	Windows 7 Home Premium
LAN	10/100 Ethernet
Battery	6-cell Lithium Ion
Ports	HDMI, VGA, RJ-45, Microphone input, Headphone output
