Toshiba Satellite L640 User Manual

Chapter 4 Replacement Procedures
Satellite L640/L645, Satellite Pro L640/Pro L645 Maintenance Manual (960-Q08)
4.5 Keyboard
Removing the keyboard
The following describes the procedure for removing the keyboard (See Figure 4-5-1 to 4-5-2).
CAUTION: As the keycap may fall out, when handling the keyboard always hold it by the
frame and do not touch the keycap.
1. Upside down the computer and remove the battery.
2. Loose the screws on KB holder.
M2.0x3.0B BIND screws x2
3. Open the display.
4. Insert your finger into the slot between the KB holder and the keyboard. Then, lift up
the keyboard holder to remove it.
5. Loose the screw securing Keyboard.
M2.0x3.0B BIND screws x3
6. Insert your finger into the slot between keyboard and Top cover Assembly. Then lift
up the keyboard to remove it.
7. Disconnect keyboard cable.

Toshiba Satellite L640 Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	802.11b/g/n
Webcam	Integrated Webcam
Processor	Intel Core i3/i5
RAM	Up to 8GB DDR3
Storage	320GB HDD
Display	14-inch HD
Graphics	Intel HD Graphics
Operating System	Windows 7 Home Premium
LAN	10/100 Ethernet
Battery	6-cell Lithium Ion
Ports	HDMI, VGA, RJ-45, Microphone input, Headphone output
