Toshiba Satellite L640 User Manual

Chapter 4 Replacement Procedures
4
4.8 Display Assembly
Removing the display assembly
The following describes the procedure for removing the display assembly (See Figure 4-8-1
to 4-8-7).
1. Close the display and turn the computer upside down.
2. Remove the battery pack (See Figure 4-2-1)
3. Open RAM Door and remove memory slot cover (See Figure 4-4-1)
4. .Remove the screws of the ODD and ODD Bezel.
Figure 4-8-1 Remove the screw on ODD Bezel and ODD
5. Remove the screws from the bottom side.
Satellite L640/L645, Satellite Pro L640/Pro L645 Maintenance Manual (960-Q08)
4-26

Toshiba Satellite L640 Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	802.11b/g/n
Webcam	Integrated Webcam
Processor	Intel Core i3/i5
RAM	Up to 8GB DDR3
Storage	320GB HDD
Display	14-inch HD
Graphics	Intel HD Graphics
Operating System	Windows 7 Home Premium
LAN	10/100 Ethernet
Battery	6-cell Lithium Ion
Ports	HDMI, VGA, RJ-45, Microphone input, Headphone output
