Checking the engine oil level
Low level Full level
H72037
72H001
NOTICE
• Be careful not to spill engine oil on
the vehicle components.
• Avoid overfilling, or the engine
could be damaged.
• Check the oil level on the dipstick
once again after adding the oil.
If the oil level is below or only slightly
above the low level, add engine oil of
the same type as already in the engine.
Remove the oil filler cap and add engine
oil in small
quantities at a time, checking
the dipstick. We
recommend that you use
a funnel when adding oil.
The
approximate quantity of oil needed to
raise
the level between low and full on the
dipstick is indicated as follows:
Gasoline engine
1.5 L (1.6 qt., 1.3 Imp. qt.)
Diesel engine
1.6 L (1.7 qt.,
1.4 Imp. qt.)
For the engine oil capacity,
see "Service
specifications" on page 267.
When the level
reaches within the correct
range, install the filler cap hand-tight.
Be careful not to touch the hot ex-
haust manifold.
With the engine at operating tempera-
ture and turned off, check the oil level
on the dipstick.
1. To get a correct reading, the vehicle
should be on level ground. After turning
off the engine, wait a few minutes for
the oil to drain back into the bottom of
the engine.
2. Pull the dipstick out, hold a rag under
the end and wipe it clean.
3. Reinsert the dipstick-push it in as far
as it will go, or the reading will not be
correct.
4. Pull the dipstick out and look at the oil
level while holding a rag
under the
end.
Be careful not to drop engine oil on
the vehicle components.
NOTICE
Lt CAUTION
Full level
I
a.K.
Low level
I
Add oil
A_dd_0-li~ ... + ..... l--a-. K_· ........... 11 :00 ,,11
Too full
-- ..... -1· ..... 1----- ........... 1---
Gasoline engine
Diesel engine
242
