TP-Link AC500 User Manual

7
2
Status
2.1 System Status
Choose the menu Status > System Status > System Status to load the following page.
Figure 2-1 System Status
In the Resource Utilization section, you can monitor the utilization of the memory and
CPU. It is recommended that the CPU utilization should be no more than 50%. The CPU
utilization above 85% indicates that the AC is under a high load and above 95% means AC
is completely loaded. When the CPU utilization keeps at high loads, some functions of the
AC may be abnormal. Please check to find the real reason.
In the Quick Display section, click the button
to select the desired interface and its
basic information such as interface name, type and IP address will be shown in this section.

TP-Link AC500 Specifications

General

Flash memory	32 MB
Internal memory	256 MB
Built-in processor	Yes
Processor frequency	1000 MHz
Control display unit	-
Internal memory type	DDR3
Number of processors installed	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Console port	RJ-45
Ethernet LAN (RJ-45) ports	5
Input voltage	100-240 V
Input frequency	50/60 Hz
Certification	CE, FCC, RoHS
Mounting type	Rack mounting
Product color	Black
Rack capacity	1U
LED indicators	Activity, Link, Power, System
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	802.1x RADIUS, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	AC
Package type	Box
Package depth	336 mm
Package width	528 mm
Package height	100 mm
Package weight	3520 g

Weight and Dimensions

Depth	227 mm
Width	440 mm
Height	44 mm
