TP-Link AC500 User Manual

53
7.2.3 Onekey Online
In Onekey Online Authentication, clients can pass the authentication without entering any
parameters on the login page .
Choose the menu Authentication > Portal Authentication > Onekey Online to load the
following page.
Figure 7-12 Onekey Online
Here you can view the Onekey Online Authentication information and edit the entries.
Click
to add a new entry.
Figure 7-13 Add a New Onekey Online Entry
Configure the related parameters and click OK.
Status Specify whether to turn on the Onekey Online authentication entry.
SSID Specify the SSIDs that will be enabled with Onekey Online authentication.
Note: The SSIDs labeled "Bound" are being used by other authentication
entries. If these SSIDs are selected, the original configuration will be replaced
by the current configuration.
Splash Page Select the splash page of Onekey Online authentication.
Free Authentication
Timeout
Select the free online time for users who have passed onekey online
authentication.

TP-Link AC500 Specifications

General

Flash memory	32 MB
Internal memory	256 MB
Built-in processor	Yes
Processor frequency	1000 MHz
Control display unit	-
Internal memory type	DDR3
Number of processors installed	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Console port	RJ-45
Ethernet LAN (RJ-45) ports	5
Input voltage	100-240 V
Input frequency	50/60 Hz
Certification	CE, FCC, RoHS
Mounting type	Rack mounting
Product color	Black
Rack capacity	1U
LED indicators	Activity, Link, Power, System
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	802.1x RADIUS, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	AC
Package type	Box
Package depth	336 mm
Package width	528 mm
Package height	100 mm
Package weight	3520 g

Weight and Dimensions

Depth	227 mm
Width	440 mm
Height	44 mm
