TP-Link AC500 User Manual

56
Advertisement Specify whether to enable the Advertisement feature. With this feature enabled,
you can add advertisement pictures on the authentication page. These
advertisement pictures will be displayed before the login page appears. The
required parameters are as follows:
Picture Resouce: You can add up to 5 advertisement pictures. When several
pictures are added, they will be played in a loop. There are two picture
resources: Local Upload and External Link.
Advertisement Duration Time: Specify how long the advertisement will be
displayed for. For this duration, the pictures will be played in a loop. Enter
a value from 1 to 30 seconds. If the duration time is not enough for all the
pictures, the rest will not be displayed.
Photo Carousel Interval: Specify the picture carousel interval. If this value
is set as 5 seconds, the first picture will be displayed for 5 seconds, followed
by the second picture for 5 seconds, and so on. Enter a value from 1 to 10
seconds.
Allow to Skip Advertisement: Specify whether to enable this feature. With this
feature enabled, the user can click the Skip button to skip the advertisement.
Description Specify a description for the Voucher entry to make it easier to search for and
manage.
7.2.5 SMS
In SMS Authentication, the client can get a verification code using a mobile phone and
enter the code to pass the authentication.
Choose the menu Authentication > Portal Authentication > SMS to load the following
page.
Figure 7-16 SMS Page
Here you can view the SMS Authentication information and edit the entries.
Click
to add a new entry.

TP-Link AC500 Specifications

General

Flash memory	32 MB
Internal memory	256 MB
Built-in processor	Yes
Processor frequency	1000 MHz
Control display unit	-
Internal memory type	DDR3
Number of processors installed	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Console port	RJ-45
Ethernet LAN (RJ-45) ports	5
Input voltage	100-240 V
Input frequency	50/60 Hz
Certification	CE, FCC, RoHS
Mounting type	Rack mounting
Product color	Black
Rack capacity	1U
LED indicators	Activity, Link, Power, System
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	802.1x RADIUS, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	AC
Package type	Box
Package depth	336 mm
Package width	528 mm
Package height	100 mm
Package weight	3520 g

Weight and Dimensions

Depth	227 mm
Width	440 mm
Height	44 mm
