TP-Link AC500 User Manual

39
6
Wireless
6.1 Wireless Service
Choose the menu Radio > Wireless > Wireless Service to load the following page.
Figure 6-1 Wireless Service
Specify and view the wireless service on this page. Click to create a new wireless
service. Click
button, you can go into the radio binding page.
Figure 6-2 Add a New Wireless Service
Status Specify whether to enable the wireless network.
SSID Specify the SSID (Service Set Identifier) for the wireless network. The SSID
should be unique.
Description Specify a description for the entry to make it easier to search for and manage.
AP Isolation Enable AP isolation to isolate the wireless clients connected to the same AP
so that they cannot communicate with each other. This setting cannot take
effect in other APs; that is, AP isolation cannot isolate the clients connected to
different APs with the same SSIDs.

TP-Link AC500 Specifications

General

Flash memory	32 MB
Internal memory	256 MB
Built-in processor	Yes
Processor frequency	1000 MHz
Control display unit	-
Internal memory type	DDR3
Number of processors installed	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Console port	RJ-45
Ethernet LAN (RJ-45) ports	5
Input voltage	100-240 V
Input frequency	50/60 Hz
Certification	CE, FCC, RoHS
Mounting type	Rack mounting
Product color	Black
Rack capacity	1U
LED indicators	Activity, Link, Power, System
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	802.1x RADIUS, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	AC
Package type	Box
Package depth	336 mm
Package width	528 mm
Package height	100 mm
Package weight	3520 g

Weight and Dimensions

Depth	227 mm
Width	440 mm
Height	44 mm
