TP-Link AC500 User Manual

44
1 Choose the menu Authentication > MAC Authentication > MAC Address to bind the
MAC addresses and VLANs of the clients to be authenticated.
2 Choose the menu Authentication > MAC Authentication > MAC Authentication to set
MAC authentication rule on the VLANs.
7.1.1 MAC Address
Choose the menu Authentication > MAC Authentication > MAC Address to load the
following page.
Figure 7-2 MAC Address
You can click Backup to back up all the MAC authentication entries in the CSV file which
are in ANSI coding format. This file can be restored to the AC and all MAC addresses can
be added into the MAC address list.
To add multiple MAC address entries at a time:
1 Save the MAC address entries as a CSV file with ANSI coding format in the AC. You can
use the Backup MAC Address function to obtain a CSV file to view the correct format.
2 Click Browse to select the file path, and then click Restore to restore the file.
Note:
Using Excel to open the CSV le may cause some numerical format changes, and the number may be displayed
incorrectly. If you use Excel to edit the CSV le, please set the cell format as text.
In the MAC address list you can view the MAC address entries.
Click
to add a new MAC address entry, as shown in the following figure.

TP-Link AC500 Specifications

General

Flash memory	32 MB
Internal memory	256 MB
Built-in processor	Yes
Processor frequency	1000 MHz
Control display unit	-
Internal memory type	DDR3
Number of processors installed	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Console port	RJ-45
Ethernet LAN (RJ-45) ports	5
Input voltage	100-240 V
Input frequency	50/60 Hz
Certification	CE, FCC, RoHS
Mounting type	Rack mounting
Product color	Black
Rack capacity	1U
LED indicators	Activity, Link, Power, System
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	802.1x RADIUS, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	AC
Package type	Box
Package depth	336 mm
Package width	528 mm
Package height	100 mm
Package weight	3520 g

Weight and Dimensions

Depth	227 mm
Width	440 mm
Height	44 mm
