TP-Link AC500 User Manual

28
Upgrade Status Displays the upgrade status of current APs of this model. Click to check the
detailed upgrade information of each AP of this model.
Latest: There is no AP of the current model to be upgraded.
Waiting: APs of the current model are waiting to be upgraded.
Upgrading: Some APs of the current model are upgrading.
Completed: All APs of the current model are upgraded.
Terminated: The upgrade was disabled while the AP was waiting to upgrade.
The AP's upgrade process is terminated. When the upgrade is enabled again,
the status of the AP will change to "Waiting".
Operation Click Import to import the upgrade firmware into the system.
Click Delete to delete the firmware.
Note:
1. Only one model can upgrade at a time.
2. When the AC reboots or the CAPs reboot automatically, the CAPs can only upgrade after ten minutes.
3. The parameter of upgrade process and upgrade failure will be cleared when the AC reboots.
4. The standby link doesn't support upgrade schedule.
4.3 AP Database
Import the AP database file to support the identification and management of new AP
models on this page. When there is an undetected AP model connecting to the AC, the AC
should import the latest AP database to identify the new AP models.
Choose the menu AP Control > AP Database > AP Database to load the following page.
Figure 4-6 AP Settings
Current Version Displays the current version of the AP database.
File Path Click Browse to locate and select the new AP database. Click Upgrade to
import it.
Download the latest AP
database
Click Download the latest AP database. You will be redirected to the TP-Link
download center to download the AP database files. The download center will
update the AP database file.

TP-Link AC500 Specifications

General

Flash memory	32 MB
Internal memory	256 MB
Built-in processor	Yes
Processor frequency	1000 MHz
Control display unit	-
Internal memory type	DDR3
Number of processors installed	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Console port	RJ-45
Ethernet LAN (RJ-45) ports	5
Input voltage	100-240 V
Input frequency	50/60 Hz
Certification	CE, FCC, RoHS
Mounting type	Rack mounting
Product color	Black
Rack capacity	1U
LED indicators	Activity, Link, Power, System
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	802.1x RADIUS, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	AC
Package type	Box
Package depth	336 mm
Package width	528 mm
Package height	100 mm
Package weight	3520 g

Weight and Dimensions

Depth	227 mm
Width	440 mm
Height	44 mm
