TP-Link ARCHER C1200 User Manual

4
Chapter 1 Get to Know About Your Router
1. 2. 2. The Back Panel
The following parts (view from left to right) are located on the back panel.
Item Description
Power Port For connecting the router to a power socket via the provided power adapter.
Power On/Off Button Press this button to power on or off the router.
Reset Button
Press and hold this button for more than 5 seconds to reset the router to its
factory default settings.
USB 2.0 Port For connecting to a USB 2.0 device or a USB 2.0 printer.
Internet Port For connecting to a DSL/Cable modem, or an Ethernet jack.
Ethernet Ports (1/2/3/4) For connecting your wired devices to the router.
WPS/Wi-Fi On/Off
Button
Press and hold this button for less than 5 seconds to enable the WPS
function.
Press and hold this button for about 2 seconds to turn on or off the wireless
function of your router.
Antennas
Used for wireless operation and data transmit. Upright them for the best
Wi-Fi performance.

TP-Link ARCHER C1200 Specifications

General

Color	black
Wi-Fi Mesh System	no
Band Technology	dual
Frequency Band	2.4 ghz, 5.0 ghz
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac, n
Gigabit Ethernet Speed	yes
Antennas	3
Parental Control	yes
Firewall	none
Data Encryption	yes
Encryption Type	wpa, wpa2, wpa-psk, wpa2-psk
Ports	rj-45, usb
LAN Ports	4
WAN Ports	1
Bluetooth	no
Smart Applications	no

Weight and Dimensions

Height	6.3 inches
Width	9.6 inches
Net Weight	2.4 pounds
