TP-Link ARCHER C1200 User Manual

85
Chapter 14 Manage the Router
The figure below indicates the proper connection between the router and the Yahoo
server (www.Yahoo.com) tested through
Traceroute.
14. 4. Upgrade the Firmware
TP-Link aims at providing better network experience for users.
We will inform you throught the web management page if there’s any update firmware
available for your router. Also, the latest firmware will be released at the TP-Link official
website
www.tp-link.com, and you can download it from the Support page for free.
Note:
• Make sure you remove all attached USB devices from the router before the firmware upgrade to prevent data loss.
• Backup your router configuration before firmware upgrade.
• Do NOT turn off the router during the firmware upgrade.
14. 4. 1. Online Upgrade
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
2. When the latest firmware is available for your router, the update icon
will display
in the top-right corner of the page. Click the icon to go to the
Firmware Upgrade page.
Alternatively, you can go to Advanced > System Tools > Firmware Upgrade, and click
Check for upgrade to see whether the latest firmware is released.

TP-Link ARCHER C1200 Specifications

General

Color	black
Wi-Fi Mesh System	no
Band Technology	dual
Frequency Band	2.4 ghz, 5.0 ghz
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac, n
Gigabit Ethernet Speed	yes
Antennas	3
Parental Control	yes
Firewall	none
Data Encryption	yes
Encryption Type	wpa, wpa2, wpa-psk, wpa2-psk
Ports	rj-45, usb
LAN Ports	4
WAN Ports	1
Bluetooth	no
Smart Applications	no

Weight and Dimensions

Height	6.3 inches
Width	9.6 inches
Net Weight	2.4 pounds
