TP-Link TL-R480T+ User Manual

-38-
Note:
If the LAN IP address is changed, you must use the new IP address to login to the Router. To
guarantee a normal communication, please be sure that the Gateway address and the Subnet Mask of
the Hosts are consistent with that of the Router accordingly.
4.3.2.2 DHCP
The Router with its DHCP (Dynamic Host Configuration Protocol) server enabled can automatically
assign an IP address to the computers in the LAN.
Choose the menu Network→LAN→DHCP to load the following page.
Figure 4-14 DHCP Settings
The following items are displayed on this screen:
¾ DHCP Settings
DHCP Server:
Enable or disable the DHCP server on your Router. Select Enable to
make the Router automatically assign TCP/IP parameters to the
computers in the LAN.
Start IP Address:
Enter the Start IP address to define a range for the DHCP server to
assign dynamic IP addresses. This address should be in the same IP
address subnet with the Router’s LAN IP address. The default
address is 192.168.0.2.
End IP Address:
Enter the End IP address to define a range for the DHCP server to
assign dynamic IP addresses. This address should be in the same IP
address subnet with the Router’s LAN IP address. The default
address is 192.168.0.254.

TP-Link TL-R480T+ Specifications

General

Load Balancing	Yes
Power Supply	100-240V AC, 50/60Hz
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Firewall	Yes
VPN	PPTP, L2TP, IPSec
VPN Support	Yes
QoS	Yes
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Network Protocols	TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP
Management	Web-based
Device Type	Router
Firewall Features	IP Filtering, Domain Filtering
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
