TP-Link TL-R480T+ User Manual

-40-
Figure 4-16 DHCP Reservation
The following items are displayed on this screen:
¾ DHCP Reservation
MAC Address:
Enter the MAC address of the computer for which you want to reserve
the IP address.
IP Address:
Enter the reserved IP address.
Description:
Optional. Enter a description for the entry. Up to 28 characters can be
entered.
Status:
Activate or Inactivate the corresponding entry.
¾ List of Reserved Address
In this table, you can view the information of the entries and edit them by the Action buttons. Up
to 512 DHCP static address entries can be supported for LAN by this Router.
The first entry in Figure 4-16 indicates: The IP address 192.168.0.101 is reserved for the
computer with the MAC address 00-19-66-83-53-CF, and this entry is activated.
Note:
It's recommended that users first bind the IP address and the MAC address in 4.4.1.1 IP-MAC Binding,
then import the entries from the IP-MAC binding table to the List of Reserved Address in buck by
clicking <Import> button in Figure 4-16 DHCP Reservation.

TP-Link TL-R480T+ Specifications

General

Load Balancing	Yes
Power Supply	100-240V AC, 50/60Hz
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Firewall	Yes
VPN	PPTP, L2TP, IPSec
VPN Support	Yes
QoS	Yes
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Network Protocols	TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP
Management	Web-based
Device Type	Router
Firewall Features	IP Filtering, Domain Filtering
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
