TP-Link TL-WA500G User Manual

TL-WA500G 54M Wireless Access Point User Guide
1.3 Appearance
1.3.1 The Front Panel
Figure 1-1 TL-WA500G front panel
Viewed from left to right, the TL-WA500G has four status LEDs: Power, System, LAN and WLAN.
LED Explanation
Name Status Indication
On The AP is Powered on
Power
Off The AP is Powered off
Flashing The AP is working properly
System
Off
The AP has a hard ware error
On
There is a device linked to the corresponding port but no activity
Flashing
There is data being transmitted or received wirelessly
LAN
Off
There is no device linked to the corresponding port
Flashing
The Wireless Radio function is enabled
WLAN
Off
The Wireless Radio function is disabled
) Note:
The LEDs' explanation above shows the device's working status after initialization.
5

TP-Link TL-WA500G Specifications

General

2.4 GHz	Yes
Modulation	DBPSK, DSSS, OFDM, QPSK
Frequency band	2.4 - 2.4835 GHz
Cabling technology	10/100Base-T(X)
Maximum data transfer rate	54 Mbit/s
Wireless technology	802.11b/g
Compliance industry standards	IEEE 802.11g, IEEE 802.11b
Non-operating relative humidity (non-condensing)	10 - 90 %
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Dimensions (WxDxH)	150 x 100 x 28 mm
