TP-Link TL-WA500G User Manual

TL-WA500G 54M Wireless Access Point User Guide
It is strongly recommended that you change the factory default user name and password of the AP.
All users who try to access the AP's web-based management page or Quick Setup will be
prompted for the AP's user name and password.
)
Note:
The new user name and password can only consist of underline, dash numbers or letters but not
any spaces. It must not exceed 14 characters in length. Enter the new Password twice to confirm
it.
Click the Save button when finished.
Click the Clear All button to clear all.
4.7.6 SysLog
Selecting System Tools > System Log allows you to query the Logs of the AP on the screen
below (Figure 4-31).
Figure 4-31 System Log
The AP can keep logs of all traffic. You can query the logs to find what happened to the AP.
Click Refresh to refresh the logs.
Click Clear ALL to clear all the logs.
38

TP-Link TL-WA500G Specifications

General

2.4 GHz	Yes
Modulation	DBPSK, DSSS, OFDM, QPSK
Frequency band	2.4 - 2.4835 GHz
Cabling technology	10/100Base-T(X)
Maximum data transfer rate	54 Mbit/s
Wireless technology	802.11b/g
Compliance industry standards	IEEE 802.11g, IEEE 802.11b
Non-operating relative humidity (non-condensing)	10 - 90 %
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Dimensions (WxDxH)	150 x 100 x 28 mm
