Trane R Series Installation, Operation And Maintenance

General Data
RTAC-SVX01J-EN 13
Table 2. General Data - 60 hz units - high efficiency - IP
Size 140 155 170 185 200 225 250 275 300 350 400
Compressor
Screw
Quantity #22222223344
Nominal size
@60Hz
(tons) 70/70 85/70 85/85 100/85 100/100 120/100 120/120
85-85/
100
100-100/
100
85-85/
85/85
100-100/
100-100
Evaporator
Flooded
Water storage(gal)34364039434343727283 91
2 pass arrangement
Min flow (gpm) 202 217 241 217 241 241 241 375 375 404 461
Max flow (gpm) 741 796 883 796 883 883 883 1374 1374 1483 1690
Water conn(NPS-in)66666668888
3 pass arrangement
Min flow (gpm) 135 145 161 145 161 161 161 250 250 270 307
Max flow (gpm) 494 531 589 531 589 589 589 916 916 989 1127
Water conn(NPS-in)44444446688
Condenser
Fin and tube
Qty of coils#44444888888
Coil length (in) 180/180 216/180 216/216 252/216 252/252 144/144 144/144 216/144 252/144 216/216 252/252
Coil height (in) 42 42 42 42 42 42 42 42 42 42 42
Number of rows # 192 192 192 192 192 192 192 192 192 192 192
Fins per foot(fpf)33333333333
Fan
Direct drive propeller
Quantity # 5/5 6/5 6/6 7/6 7/7 8/6 8/8 12/6 14/6 12/12 14/14
Diameter(in)30303030303030 303030 30
Air flow/fan (cfm) 9199 9199 9199 9200 9201 9783 9203 9652 9605 9199 9201
Power/motor (hp) 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
Fan speed (rpm) 1140 1140 1140 1140 1140 1140 1140 1140 1140 1140 1140
Tip speed (Ft/Min) 8954 8954 8954 8954 8954 8954 8954 8954 8954 8954 8954
General unit
HFC-134a
# Refrig ckts#22222222222
% min load%15151515151515151515 15
Refrigerant charge (lb) 175/175 215/205 215/215 225/215 225/225 235/235 235/235 415/200 460/200 415/415 460/460
Oil charge (gal) 1.3/1.3 1.3/1.3 1.3/1.3 1.9/1.3 1.9/1.9 1.9/1.9 1.9/1.9
2.1-2.1/
1.9
2.3-2.3/
1.9
2.1-2.1/
2.1-2.1
2.3-2.3/
2.3-2.3
Min ambient-std (°F) 25 25 25 25 25 25 25 25 25 25 25
Min ambient-low(°F)00000000000
1. Data containing information on two circuits is shown as follows: ckt 1/ ckt 2.
2. Minimum start-up/operating ambient is based on a 5 mph wind across the condenser.
3. RTAC units must only operate with refrigerant R-134a and Trane Oil 00048.
