Device Address Binding
Networking Options
Character Sets
Indicates support for multiple characters sets, but does not
imply that all character sets are supported simultaneously.
Maximum supported string length is 64 bytes (any
character set).
Object and Diagnostic Data Points with
Corresponding Chiller Models
For quick reference, the following tables are listed two
different ways. Table 47 through Table 52 are listed by
input/output type and sorted by object identifier.These
tables
provide the user with the units type for each object
type. Table 53 is sorted by object name and provides a
complete list of object names, types, values/ranges, and
descriptions.
Not all points are available to the user.The
available data points are defined during self-configuration
and are dependent on the type of equipment.
Device Address Binding Supported?
Static Device Binding Supported ü
Networking Descriptions
Supported
Option
Annex H, BACnet Tunneling
BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD Support Registrations by Foreign
Devices?
Router
Character Set Descriptions Supported
ANSI X3.4 ü
IBM/Microsoft DBCS
ISO 10646 (UCS-4)
ISO 10646 (UCS2) ü
ISO 8859-1 ü
JIS C 6226
Table 47. Analog Output
Object Identifier Object Name Description Units Valid Range
Relinq
Default
Analog Output 1 Chilled Water Setpoint
Desired leaving water
temper
ature if chiller is in cooling
mode.
Degrees-Fahrenheit
(64)
0°F to 75°F
44°F
Analog Output 2 Current Limit Setpoint
Sets the maximum capacity that
the chiller can use.
Percent (98) 0% to 120% 100%
Analog Output 4 Hot Water Setpoint
Desired leaving water
temper
ature if chiller is in heating
mode.
Degrees-Fahrenheit
(64)
80°F to 140°F 120°F
Table 48. Analog Input
Object
Identifier
Object Name Description Units
Analog Input, 1 Active Cool/Heat Setpoint Temperature Active chiller water or hot water setpoint. Degrees-Fahrenheit (64)
Analog Input, 2 Active Current Limit Setpoint Active capacity current limit setpoint. Percent (98)
Analog Input, 5 Actual Running Capacity
Level of capacity that the chiller is currently
running at.
Percent (98)
Analog Input, 7 Suction Pressure- Ckt 1 Circuit 1 suction pressure. PSI
Analog Input, 10 Suction Pressure- Ckt 2 Circuit 2 suction pressure.
PSI
Analog Input, 12
Evaporator Saturated Refrigerant
Temperature- Ckt 1
Circuit 2 evaporator refrigerant temperature. Degrees-Fahrenheit (64)
Analog Input, 14
Evaporator Saturated Refrigerant
T
emperature- Ckt 2
Circuit 2 evaporator refrigerant temperature.
Degrees-Fahrenheit (64)
Analog Input, 16 Condenser Refrigerant Pressure- Ckt 1 Circuit 1 condenser refrigerant pressure. PSI
Analog Input, 18 Condenser Refrigerant Pressure- Ckt 2 Circuit 2 condenser refrigerant pressure.
PSI
Analog Input, 20
Condenser Saturated Refrigerant
Temperature- Ckt 1
Circuit 1 condenser refrigerant temperature. Degrees-Fahrenheit (64)
Analog Input, 22
Condenser Saturated Refrigerant
T
emperature- Ckt 2
Circuit 2 condenser refrigerant temperature.
Degrees-Fahrenheit (64)
Analog Input, 24 Unit Power Consumption The power being consumed by the chiller. Kilowatts
