Trane R Series Installation, Operation And Maintenance

Diagnostics
RTAC-SVX01J-EN 161
Starter Module
Memory Error Type
1Starter 1A
None Info Latch All
Checksum on RAM copy of the Starter LLID configuration failed.
Configuration recalled from EEPROM.
Local
Starter Module
Memory Error Type
1-Starter 1B
None Info Latch All
Checksum on RAM copy of the Starter LLID configuration failed.
Configuration recalled from EEPROM.
Local
Starter Module
Memory Error Type 2
- Starter 1A
Cprsr Immediate Latch All
Checksum on EEPROM copy of the Starter LLID configuration
failed. Factor default values used.
Local
Starter Module
Memory Error Type 2
- Starter 1B
Cprsr Immediate Latch All
Checksum on EEPROM copy of the Starter LLID configuration
failed. Factor default values used.
Local
Starter Module
Memory Error Type 2
- Starter 2A
Cprsr Immediate Latch All
Checksum on EEPROM copy of the Starter LLID configuration
failed. Factor default values used.
Local
Starter Module
Memory Error Type 2
- Starter 2B
Cprsr Immediate Latch All
Checksum on EEPROM copy of the Starter LLID configuration
failed. Factor default values used.
Local
Starter Panel High
Temperature Limit -
Panel 1, Cprsr 1B
Cprsr 1B
Special
Mode
NonLatch All
Starter Panel High Limit Thermostat (170 F) trip was detected.
Note: Other diagnostics that may occur as an expected
consequence of the Panel High Temp Limit trip will be
suppressed from annunciation. These include Phase Loss,
Power Loss, and Transition Complete Input Open for Cprsr 1B
Local
Starter Panel High
Temperature Limit -
Panel 1, Cprsr 2A
Cprsr 2A
Special
Mode
NonLatch All
Starter Panel High Limit Thermostat (170 F) trip was detected.
Note: Other diagnostics that may occur as an expected
consequence of the Panel High Temp Limit trip will be
suppressed from annunciation. These include Phase Loss,
Power Loss, and Transition Complete Input Open for Cprsr 2A
Local
Starter Panel High
Temperature Limit -
Panel 2, Cprsr 2B
Cprsr 2B
Special
Mode
NonLatch All
Starter Panel High Limit Thermostat (170 F) trip was detected.
Note: Other diagnostics that may occur as an expected
consequence of the Panel High Temp Limit trip will be
suppressed from annunciation. These include Phase Loss,
Power Loss, and Transition Complete Input Open for Cprsr 2B
Local
Suction Refrigerant
Pressure Transducer
- Circuit 1,
Compressor 1A
Special Immediate Latch All
Bad Sensor or LLID Circuit target if no isolation valves,
Compressor target if isolation valves. Design Note: In the case
of manifolded compressors w/o isolation valves, the occurrence
of this diagnostic will also generate a comm loss with the
nonexistent Suction Press Cprsr 1B in order to accomplish circuit
shutdown.
Remote
Suction Refrigerant
Pressure Transducer
- Circuit 1,
Compressor 1B
Cprsr 1B Immediate Latch All
Bad Sensor or LLID. Design Note: For circuits with manifolded
compressors w/o isolation valve option, this diagnostic will occur
with the preceding diagnostic, even though this transducer is not
required or installed.
Remote
Suction Refrigerant
Pressure Transducer
- Circuit 2,
Compressor 2A
Special Immediate Latch All
Bad Sensor or LLID Circuit target if no isolation valves,
Compressor target if isolation valves. Design Note: In the case
of manifolded compressors w/o isolation valves, the occurrence
of this diagnostic will also generate a comm loss with the
nonexistent Suction Press Cprsr 2B in order to accomplish circuit
shutdown.
Remote
Suction Refrigerant
Pressure Transducer
- Circuit 2,
Compressor 2B
Cprsr 2B Immediate Latch All
Bad Sensor or LLID. Design Note: For circuits with manifolded
compressors w/o isolation valve option, this diagnostic will occur
with the preceding diagnostic, even though this transducer is not
required or installed
Remote
Very Low Evaporator
Refrigerant Pressure
- Circuit 1
Chiller Immediate Latch
All
[compressor or
circuit in manual
lockout]
The evaporator pressure dropped below 8 psia (or 5 psia in sftw
prior to Oct '02)regardless of whether or not compressors are
running on that circuit. This diagnostic was created to prevent
compressor failures due to crossbinding by forcing an entire
chiller shutdown. If a given compressor or circuit is locked out,
the suction pressure transducer(s)associated with it, will be
excluded from causing this diagnostic.
Local
Table 67. Main processor diagnostics (continued)
Diagnostic Name
Affects
Target Severity
Persist-
ence
Active Modes
[Inactive
Modes] Criteria
Reset
Level
