Operation Sageon Micro Power Module Manual
PM990-4207-00, Rev 6
5-8
5.3.2 RECTIFIER Menu (Rectifier Specific Functions)
The RECTIFIER Float and Equalize voltages are the default values set in the rectifier that will be used if the
Controller fails to operate. They are a copy of the raw values set in the BATTERY menu without battery
temperature compensation and system drop adjustments.
5.3.3 Alarm Log
25.2A 54.3V
FL
⇒ SMR Button
ENTER SMR software version
(↑)
S
MR1
13.2A 58°C
SMR1
S/W 137901
INC ENTER Additional screens if more
(↓)
SMR2
:
SMR2
:
SMRs are declared
Float Voltage - SMR Default
SMR Float
54.5V
*Cannot be adjusted here
Equalise Voltage - SMR Default
SMR Equalise
56.5V
*Cannot be adjusted here
ENTER SMR voltage above which alarm flagged
Modify Value up/down
ENTER to accept
ENTER SMR voltage below which alarm flagged
Modify Value up/down
ENTER to accept
ENTER SMR high voltage shutdown
Modify Value up/down
ENTER to accept
Modify Value up/down
ENTER to accept
Resets any latched SMR alarm
Reset SMR Fault
Press ENTER
25.2A 54.3V
FL
⇒ LOG Button
ENTER Most recent logged Alarm/Event
LOG 1
AC Fail
10/10/2005
17:32:56
ENTER Additional screens if more events logged
DEC ENTER 100th most recent logged event
LOG 100
Battery Sw Open
3/1/2005
02:05:14
Older events are erased
(↓)
DEC to Clear
LOG Entries
LOG
No Entries
