UAD Powered Plug-Ins Manual - 194 - Chapter 20: Manley Massive Passive EQ
Frequency This control defines the center frequency (Bell mode) or edge
frequency (Shelf mode) for the band. Each band provides a
wide range of specially tuned overlapping and interleaving
frequency choices. The available frequencies for each band
are listed in Table 18 below.
Available
Frequencies
Channel Controls
The controls for the two identical channels (left and right) are
detailed below. Because both UAD Massive Passive plug-ins
operate the same way (and the controls for each channel are
identical), the control descriptions for each channel are only
detailed once.
Note: See “Standard vs. Mastering Versions” on
page 190” for the exact differences between the Massive
Passive parameters.
EQ In The EQ In pushbutton switch enables the channel. When the button illu-
minates in a brighter blue, the channel is active and the other channel
controls will affect the signal. When this control is disabled, all the de-
sirable low-level system filtering and coloration is retained in the channel, just
like the original hardware.
Channel Gain This knob sets the overall gain for the channel. The range for the
standard version is continuously variable from –6 dB to +4 dB. The
range for the Mastering version is ±2.5 dB, in 0.5 dB steps.
Table 18. Available band frequencies (standard and mastering)
Massive Passive Band Selectable Frequencies (Hz)
Low 22, 33, 47, 68, 100, 150, 220, 330, 470, 680, 1K
Low Mid 82, 120, 180, 270, 390, 560, 820, 1.2K, 1.8K, 2.7K, 3.0K
High Mid 220, 330, 470, 680, 1K, 1.5K, 2.2K, 3.3K, 4.7K, 6.8K, 10K
High 560, 820, 1.2K, 1.8K, 2.7K, 3.9K, 5.6K, 8.2K, 12K, 16K, 27K
