UAD Powered Plug-Ins Manual - 71 - Chapter 5: CS-1 Channel Strip
RS-1 Controls
Sync Button This button puts the plug-in into Tempo Sync mode. See Chapter 8 in the UAD
System Manual for more information.
Shape Pop-up
Menu
Determines the shape of the reverberant space, and the resulting reflective
patterns.
Delay Knob Sets the delay time between the original signal and the onset of the reflec-
tions.
Size Knob Sets the size of the reverberant space (from 1–99 meters) and defines the
spacing of the reflections.
Delay/Size
Settings
Interaction
You may notice that when Delay is set to its maximum value and the Size con-
trol is moved to its maximum value, the Delay value is decreased, and vice
versa. This occurs because the maximum delay time available to the plug-in
has been reached — the available delay time is limited and is divided among
the Delay and Size values. Therefore, if the value of the Delay or Size setting
is increased towards maximum when the other control is already high, its
complementary setting may be reduced.
Recirculation
(RECIR) Knob
Sets the amount of processed signal fed back into its input. Higher values in-
crease the number of reverberations/delays and intensity of the processed
signal.
Table 8. Available RS-1 Shapes
Cube Square Plate
Box Rectangular Plate
Corr Triangular Plate
Cylinder Circular Plate
Dome Echo
Horseshoe Ping Pong
Fan Echo 2
Reverse Fan Fractal
A-Frame Gate 1
Spring Gate 2
Dual Spring Reverse Gate
