UAD Powered Plug-Ins Manual - 233 - Chapter 25: Neve 31102 Console EQ
EQL The equalizer is engaged when the EQL switch is in the “In” (darker)
position. To disable the EQ, put the switch in the “Out” (lighter) posi-
tion. Click the button to toggle the state.
In the hardware 31102, the audio is still slightly colored even when the EQL
switch is in the Out position. This is due to the fact that the signal is still pass-
ing through its circuitry. Therefore, the signal will be slightly colored when this
switch is in the Out position. UAD DSP usage is reduced when the EQ is by-
passed with this control (unless UAD-2 DSP LoadLock is enabled).
If a true bypass is desired, use the OFF position of the Input Gain control (“In-
put Gain” on page 230).
Neve 31102SE
Overview The UAD Neve 33102SE is derived from the UAD Neve 31102. Its algorithm
has been revised in order to provide sonic characteristics very similar to the
31102 but with significantly less DSP usage. It is provided to allow 31102-
like sound when DSP resources are limited. Nobody with “golden ears” will
say it sounds exactly like the 31102, but it still sounds great and is very us-
able in most situations.
The 31102 interface can be differentiated from the 31102 by color and the
module name. The 31102SE background is black instead of the 31102’s
dark blue, and the module name on the lower right of the interface panel in-
cludes “SE”.
Neve 31102SE
Controls
The Neve 31102SE controls are exactly the same as the Neve 31102. Please
refer to “Neve 31102 and 31102SE Controls” on page 230 for Neve
31102SE control descriptions.
Figure 73. The Neve 31102SE plug-in window
