UAD Powered Plug-Ins Manual - 334 - Chapter 38: RealVerb Pro
RealVerb Pro Background
Figure 105 illustrates the signal flow for RealVerb Pro. The input signal is
equalized and applied to the early reflection generator and the late-field re-
verberation unit. The resulting direct path, early reflection, and late-field re-
verberation are then independently positioned in the soundfield.
Figure 105. RealVerb Pro signal flow
Figure 106. The RealVerb Pro plug-in window
Late-
Field
Reverb
EQ
Source
Input
Early
Reflections
Direct Path
Pan
Pans &
Distance
Gain
Output
Delay
Delay
Wet/Dry
Mix
Gain &
Mute
