0020308120_02 Air/flue pipe installation manual 49
5.14.3.2 Installing the 45° elbow, 60/100 mm diameter
A Offset
B Length of the air pipe
C Height
▶ Measure the offset (A), e.g. with 300 mm.
▶ Use this value from the table to determine the length of the air pipe (B) = 284 mm and the height (C) = 420 mm.
◁ From that, the corresponding flue pipe length is calculated as 284 + 40 = 324 mm.
Offset Length of
the air pipe
Height Offset Length of
the air pipe
Height in Offset Length of
the air pipe
Height in
90 0 210 325 320 445 525 602 645
95 0 215 330 327 450 530 610 650
100 0 220 335 334 455 535 617 655
> 105 to <
155
not possible not possible 340 341 460 540 624 660
345 348 465 545 631 665
350 355 470 550 638 670
355 362 475 555 645 675
160 86 280 360 369 480 560 652 680
165 93 285 365 376 485 565 659 685
170 100 290 370 383 490 570 666 690
175 107 295 375 390 595 575 673 695
180 115 300 380 397 500 580 680 700
185 122 305 385 404 505 585 687 705
190 129 310 390 412 510 590 694 710
195 136 315 395 419 515 595 701 715
200 143 320 400 426 520 600 709 720
205 150 325 405 433 525 605 716 725
210 157 330 410 440 530 610 723 730
215 164 335 415 447 535 615 730 735
220 171 340 420 454 540 620 737 740
225 178 345 425 461 545 625 744 745
230 185 350 430 468 550 630 751 750
235 192 355 435 475 555 635 758 755
240 199 360 440 482 560 640 765 760
245 206 365 445 489 565 645 772 765
250 214 370 450 496 570 650 779 770
255 221 375 455 503 575 655 786 775
260 228 380 460 511 580 660 793 780
265 235 385 465 519 585 665 800 785
270 242 390 470 525 590 670 808 790
275 249 395 475 532 595 675 815 795
