Valent Controls IOM 10 IOM-C1-0616
Part Number 474626
Reviewing LonWorks Settings
The LonWorks settings for the JENEsys
controller are available in the POINTS menu of
the LCD display. To access them:
1. Push any button on the LCD interface to
refresh the display. If the main menu is not
shown, press the MENU button to return to the
main menu.
2. Press Enter to select POINTS. The UNIT
STATUS menu is the first menu displayed.
3. Press the right arrows below LAST to jump to
the last tab of the points menu, which is for
COMMUNICATIONS.
4. Use ▼ to scroll down to reach the LonTalk
points.
LonTalk is an optional feature which must be
licensed. Although data will appear for viewing
on the communications menu, settings cannot
be changed if the unit has not been licensed.
Service Pin
The SERVICE PIN is available to help discover
the Valent unit on the building’s LON network.
1. On the LonWorks menu, navigate to
SERVICE PIN.
2. Press Enter to make the point editable.
Toggle ▲ or ▼ to make the value TRUE,
then press Enter. This sends a service pin
signal over the LON network. This can be
repeated as many times as necessary.
Refer to Using LonTalk Communications on page 25
for further information about LonTalk
communications.
