valent VPR Series User Manual

Valent Controls IOM 29 IOM-C1-0616
Part Number 474626
Setpoint List
Setpoints, listed by the Description name, are defined in the Setpoint Descriptions section on page 40.
Description
UMT Name
 = Editable
LCD Name
 = Editable
Web UI Name
 = Editable
Min
Max
Default
States
1.0 Air Cooled Head Pressure
Setpoint
1.0 Air Cooled Head Pressure
Setpoint
—
Air Cooled Cond Temp
90°F
140°F
115°F
—
10 Volts Opens Chilled Water
Valve
10 Volts Opens Chilled Water
Valve
—
—
—
—
False
False, True
10 Volts Opens Hot Water Valve
10 Volts Opens Hot Water Valve
—
—
—
—
True
False, True
2.0 Air Cooled Head Pressure
Dehumidification Setpoint
2.0 Air Cooled Head Pressure
Dehumidification Setpoint
—
Air Cooled Cond Temp
90°F
140°F
115°F
—
2.0 Air Cooled Head Pressure
Setpoint
2.0 Air Cooled Head Pressure
Setpoint
—
Air Cooled Cond Temp
90°F
140°F
115°F
—
Air Flow Monitoring Damper Area
AMD Damper Area
—
Damper Area
—
—
—
—
Air Flow Monitoring Damper Flow
AMD Airflow
AMD
Air Flow AMD
—
—
—
—
Air Flow Monitoring Damper K
Factor
AMD K Factor
—
K Factor AMD
—
—
—
—
Air Flow Monitoring Damper M
Factor
AMD M Factor
—
M Factor
—
—
—
—
Air Flow Monitoring Damper
Setpoint
Damper Setpoint
SETPOINT
Damper Spt
—
—
0 cfm
—
Air Flow Monitoring Device
Transducer Range
AMD Transducer Range
—
AMD Transducer Range
—
—
0-1 InWc
0-.25, 0-.5, 0-1, 0-2
Air Flow Monitoring Exhaust
Cone Flow
Exhaust Airflow
EXHAUST
Air Flow Exhaust
—
—
—
—
Air Flow Monitoring Exhaust
Cone K Factor
Exhaust Inlet Cone K Factor
—
K Factor Exhaust Fan
—
—
—
—
Air Flow Monitoring Supply Cone
Flow
Supply Airflow
SUPPLY
Air Flow Supply
—
—
—
—
Air Flow Monitoring Supply Cone
K Factor
Supply Inlet Cone K Factor
—
K Factor Supply Fan
—
—
—
—
Air Flow Monitoring Thermal
Dispersion Damper Max Velocity
AMD Thermal Dispersion Max
Velocity
—
TD AMD Max Velocity
—
—
—
—
Air Flow Monitoring Type
Type
—
AFMS Installed?
—
—
—
—
Air Source Heat Pump Allow
Defrost Mode
ASHP Allow Defrost Mode
—
—
—
—
True
False, True
Air Source Heat Pump Defrost
Cancel Condensing Setpoint
ASHP Defrost Cancel
Condensing Setpoint
—
ASHP Defrost Cancel
55°F
80°F
60°F
—
Air Source Heat Pump Defrost
Status
ASHP Defrost Status
ASHP
—
—
—
Normal
Normal, 1x Defrost, 2x Defrost,
3x -> Aux Heat, Defrosting, Defrost
Disabled, Low Sat -> Aux Heat,
Low Amb -> Aux Heat, Aux Heat,
Not Installed
Air Source Heat Pump Electric
Heat Defrost
ASHP Electric Heat Defrost
—
—
—
—
Disabled
Enabled, Disabled
Air Source Heat Pump Electric
Heat Defrost Enable
ASHP Electric Heat Defrost
Enable. Call Valent for
Password.
—
ASHP Electric Defrost
—
—
—
Password required.
Air Source Heat Pump Low
Ambient Compressor Lockout
Setpoint
ASHP Low Ambient Compressor
Lockout Setpoint
—
ASHP Low Ambient
10°F
50°F
17°F
—
Alarm Reset
Alarm Reset
ALARM RESET
Alarm Reset
—
—
False
False, True
Alarm Status
Alarm Status
ALARM STATUS
Alarm Status
—
—
Normal
Alarm, Normal
Ambient Cooling Lockout
AMB Lockout
AMB LOCKOUT
Cooling Lockout
50°F
90°F
55°F
—
Ambient Heating Lockout
AMB Lockout
AMB LOCKOUT
Heating Lockout
65.0°F
100.0°F
80.0°F
—
BACnet Time Synch
Time Synch
—
—
—
—
Disabled
—
BACnet UDP Port
UDP Port Number
—
—
—
—
47808
—
Bapi Space Sensor Enable
Bapi Space Sensor Enable
—
—
—
—
False
False, True
Chilled Water Valve Position
When Unit Off
Chilled Water Valve Off Position
—
—
Closed
Closed, Open
CO2 Control
CO2 Control
—
CO2 Enabled
—
—
—
Enabled, Disabled
CO2 Damper Maximum Position
Maximum Damper Control
Position
—
CO2 Damper Max
0%
100%
30%
—
CO2 Deadband
CO2 Deadband
—
CO2 Deadband
0 ppm
500 ppm
100 ppm
—
