Valent Controls IOM 34 IOM-C1-0616
Part Number 474626
BACnet Setpoint List
Setpoints, listed by the Description name, are defined in the Setpoint Descriptions section on page 40.
* BAS reported sensor values: Sensor readings as relayed by a building management system override any hardwired sensors connected to the unit.
** All editable BACnet points can be written to at the following priorities: in2, in3, in4, in5, in7, in8, in9, in10, in11, in12, in13, in14, in15, in16.
Description =Editable**
DX Coil Leaving Temperature
Outdoor Relative Humidity
Circuit A Refrigerant Pressure
Circuit B Refrigerant Pressure
Air Flow Monitoring Station CFM
Hot Gas Reheat Percentage
Digital Scroll Compressor Percentage
Chilled Water Valve Position
Modulating Heat Percentage, Primary
Modulating Heat Percentage, Secondary
Head Pressure Analog Output Status
Heat Pump Water Valve A Percentage
Heat Pump Water Valve B Percentage
Space Temperature Setpoint from BAS *
Supply Temperature Setpoint from BAS *
Space Humidity Setpoint from BAS *
CO2 Level Setpoint from BAS *
Supply Duct Static Pressure Setpoint from BAS *
Supply Duct Pressure Setpoint
Space Static Pressure Setpoint from BAS *
BAS Reported Space Temperature *
BAS Reported Space Relative Humidity *
BAS Reported Outdoor Relative Humidity *
BAS Reported Outdoor Air Temperature *
BAS Reported Space Static Pressure *
BAS Reported Supply Duct Static Pressure *
BAS Reported Space CO2 Level *
Exhaust Fan BAS Speed Command *
BAS Remote Damper Signal *
Supply Fan BAS Speed Command *
Air Flow Monitoring Station CFM 2
