VAT 612 Series User Manual

Series 612 INSTALLATION
605262EE Edition 2018-08-20 45/
116
4.6.4 Valve configuration
Basic valve configuration must be adapted according to application needs.
Definition of valve plate position in case of:
• After power up, default is ‘close‘.
• Power failure, default is ‘not defined‘. Only for versions that have Power Fail Option equipped [612 . .
- . . C . - . . . . or 612 . . - . . H . - . . . . ].
• Network failure, for default settings refer to individual product data sheet.
Local operation:
(‘Control View’, ‘Control Performance Analyzer’
or ‘Service Box 2‘)
Remote operation:
With CPA:
• Do valve configuration in menu ‘Valve
/ Setup’.
With SB2:
• Do power up configuration in menu
‘Setup / Valve’.
• Do power fail configuration in menu
‘Setup / Valve’.
It is not possible to do ‘Valve
configurations’ via EtherCAT.
