VAT 642 Series User Manual

Series 642 SPARE PARTS
742280ED Edition 2017-11-24 115/
119
All “Item“ refer to chapter «Drawing»
12.1.1 Valve unit with seals and grease
Item Description DN 63 DN 80 DN 100 DN 160 DN 200 DN 250 DN 320
DN 350
DN 400
3 Bonnet seal 77775-R1 77775-R1 77778-R1 77781-R1 77784-R1 N-5100-378 N-5100-382 N-5100-383
4 Gate assembly 591063 590996 590858 84275-R1 84608-R1 83481-R1 409173 215561
5 Gate O-ring N-5102-340 220113 N-5102-351 N-5102-364 N-5100-372 N-5102-453 N-5102-457 N-5100-461
6 Crank bolt 79090-R1 79090-R1 79090-R1 79090-R1 79090-R1 85783-R1 85783-R1 87749-R1
7
Crank bolt
mounting screw
with spring
washer
N-6005-458
N-6162-405
N-6005-458
N-6162-405
N-6005-458
N-6162-405
N-6005-458
N-6162-405
N-6005-458
N-6162-405
N-6005-502
N-6162-407
N-6005-502
N-6162-407
N-6005-502
N-6162-407
8
Feedtrough
connection pin
N-6097-478 N-6097-478 N-6097-478 N-6097-480 N-6097-480 N-6097-509 N-6097-509 N-6097-509
14
Actuator:
standard
with pumping port
546656
489236
546656
489236
546656
489236
478357
487706
478357
487706
711045
539937
711045
539937
707681
587193
11
Static actuator
seal
N-5100-222 N-5100-222 N-5100-222 N-5100-225 N-5100-225 N-5100-228 N-5100-228 N-5100-228
21
Locking balls
N-6121-052
(8 pcs)
N-6121-052
(8 pcs)
N-6121-052
(12 pcs)
N-6121-051
(18 pcs)
N-6121-051
(24 pcs)
N-6121-081
(18 pcs)
N-6121-081
(24 pcs)
N-6121-097
(32 pcs)
23 Controller On request. To many to list.
22
Ball bearing
assembly
66856-R1
(1 pc)
66856-R1
(1 pc)
67064-R1
(2 pcs)
84326-R1
(2 pcs)
80642-R1
(2 pcs)
99205-R1
(4 pcs)
99205-R1
(4 pcs)
77286-01
(4 pcs)
Seal kit vacuum 97442-R1 225315 97446-R1 85047-R1 95939-R1 98472-R1 98474-R1 98476-R1
Feedtrough
assembling tool
91001-R1 227400
VAT vacuum
grease (40g)
N-6951-012
