4.6.2 Interface configuration
Interface configuration must be adapted according to application needs (Master valve only).
• Functionality of digital interlock inputs CLOSE VALVE and OPEN VALVE. These may be configured
as ‘not inverted‘, ‘inverted‘ or ‘disabled‘. Default is ‘not inverted‘. Refer also to «Digital inputs».
• Pressure and position range for RS232 communication must be selected. Default for pressure is 0 -
1’000’000. Default for position is 0 - 100’000.
Local operation:
(‘Control View’, ‘Control Performance Analyzer’
or ‘Service Box 2‘)
Remote operation:
(Refer to chapter «setup commands» for details)
Do configuration in menu ‘Setup / Interface’.
1. Send INTERFACE CONFIGURATION
2. Send RANGE CONFIGURATION
4.6.3 Cluster address configuration
When setting up the valve cluster solution, each valve needs a unique cluster address.
This address must be configured on each valve prior to operation via the service port by using the
graphical interface (SETUP –> CLUSTER) or the Terminal function of the Control View software or
Control Performance Analyzer software. The used addresses must be in a consecutive order.
Further the Master valve needs the information about the total number of valves (including itself)
connected to the valve cluster.
Prior to sending the address command, set the valve to LOCAL operation.
