Vision 1612 User Manual

Page 27
Chapter 8
Spindle Assembly Description
Chapter 8:
Table Adjustments
(Figure 8.1)
The Series 3 Top-Loading
Spindle Assembly
1. Pulley
2. Inner Spindle Housing (under sleeve)
3. Outer Spindle Sleeve
4. Pressure Spring Adjuster
5. Pressure Spring
6. Pointer
7. Micrometer
8. Retainer Ring
(Figure 8.2) The Series 3 Top and
Bottom-Loading Collet Spindle
Assembly
1.
2.
3.
4.
5.
6.
7.
8.
10.
9.
13.
12.
11.
9. Nose Cone
10. Cutter
11. Solid Collet (Optional)
12. Split Collet (Optional)
13. Draw Bar (Optional)
14. Cutter Knob
15. Cutter Knob Setscrew
14.
15.
