63
Maintenance: Reverse gear
3. Apply a little oil to the new filter gaskets.
4. Screw on the filters by hand until the gaskets
make contact with the sealing surface on the filter
bracket. Then screw a further half turn, not any
more!
5. Top up with oil.
6. Start the engine and check for leaks.
Twin Disc MG 514
1. Undo the four bolts holding the cover.
2. Remove the cover and filter.
3. Clean the filter container and fit new filter.
4. Refit the cover and tighten the bolts.
5. Start the engine and check for leaks.
6. Check the oil level as described on the previous
page.
Seal. Lubrication
Applies only to TwinDisc reverse gear
Lubricate theseal on the output shaft bearing (with
the lubricating nipple) using a hand gun and lithium-
based grease such as Mobilux EP2, Statoil Uniway
EP2N, Texaco Multifak EP2, Q8 Rembrandt EP2.
