9
Special tools
In all cases where it is practical, tools have had their part number punched on, but not the last figure. The last fig-
ure (after the dash) is a check sum figure.
884948-1 Tool for installing crankshaft gear
884949-9 Installation tool for polygon hub
9812546-1 Plug brush for cleaning the seat and
base of the injector nozzle sleeve
9991084-5 Drift for removing valve guides, 7(x)
series.
9991459-6 Drift for removing valve guides, 6(x)
series.
9991801-3 Standard shaft, 18x200 mm
9991867-4 Drift for removing and installing rocker
arm bushes, 6(x) series.
9992000-1 Standard shaft, 25x200 mm
9992071-2 Drift for removal/installing gudgeon pins.
Also used to remove the coolant pump
9992178-5 Extractor plate for lining extractor, 7(x)
series.
9992479-7 Holder for dial gauge, for checking lining
height above block plane
9996395999639499961699996087999267999926779992669
99924979992071884948 884949 99920009991867999180199914599991084 9992178 99924799812546
9992655 9992658 9992661
9992497-9 Drift for removal/installing con rod bush,
7(x) series.
9992655-2 Extractor for polygon hub on crankshaft
9992658-6 Extractor for crankshaft gear
9992661-0 Drift for removing valve guides, 7(x)
series.
9992669-3 Drift for removal/installing con rod bush,
6(x) series.
9992677-6 Drift for removal/installing rocker bush,
7(x) series.
9992679-2 Extractor for timing gear wheels
9996087-4 Extractor plate for lining extractor, 6(x)
series.
9996169-0 Mandrel for valve guide installation, 6(x)
series.
9996394-4 Support leg (2 no.) for 9996645
9996395-1 Counterhold (2 no.) for 9996645
