Wacker Neuson RD 27-100 User Manual

Operation RD 27
26 wc_tx000814gb.fm
4.3 Operation & Maintenance Locations
Ref. Description Ref. Description
a Throttle lever l Vibration mode switch
b Ignition key block m Vibration ON/OFF switch
c Alternator warning light n Water pump switch
d Engine oil pressure warning light o Engine temperature warning light
e Hydraulic oil temperature warn-
ing light
p Hour meter
f Forward-reverse lever q Turn signal switch
g Horn r Flashers ON warning light
h Parking brake warning light and
control
s Flasher activation switch
i Vibration-on warning light t Flow divider switch (if equipped)
j Light switch u Turn signal indicator
k Fuse box v Lights ON indicator
-- -- w Light switch
Ref. Description Ref. Description
1 Diesel engine 7 Front exciter hydraulic motor
2 Hydraulic transmission pump 8 Rear hydraulic transmission
motor
3 Front hydraulic transmission
motor
9 Servo steering
4 Rear exciter hydraulic motor 10 Brake
5 Exciter hydraulic pump 11 Oil cooler
6 Steering hydraulic pump 12 Electric water pump

Wacker Neuson RD 27-100 Specifications

General

Brand	Wacker Neuson
Model	RD 27-100
Category	Power Roller
Language	English
