RD 27 Maintenance
wc_tx000815gb.fm 71
5.17 Cleaning the Water Spray System Filter
Prerequisites  Machine shut down
 Water spray system shutoff valve in closed position
When Every 10 hours of service or daily
l
Procedure Follow the procedure below to clean the water spray system filter.
1. Locate the water spray system filter assembly (a) inside the step on the right
side of the machine.
2. Open the drain valve (b).
3. Unscrew and remove the filter bowl (d).
4. Remove the filter (c).
5. Clean the filter with water or compressed air.
6. Clean the filter bowl with water or compressed air.
7. Check the condition of the sealing gasket (e) and replace it if necessary.
8. Re-install the filter into the filter bowl, pressing down firmly to seat it in place.
9. Re-install the filter bowl.
10.Close the drain valve.
e
