Seat switch
parts list
5.5 Maintaining the Seat and Seat Belt
Background
In order for the seat and seat belt to operate safely and properly over a long period
of time, periodic maintenance and occasional repairs are necessary. Poorly
maintained equipment can become a safety hazard!
Maintaining
the seat and
seat belt
Keep the seat clean. Dirt, dust, or harsh chemicals can damage the upholstery.
Repair holes or tears immediately.
If necessary, clean the seat belt with a mild soap solution. Do not use chemical
cleaners, as they will damage the fabric.
Periodically test the operation of the seat tension knob and the front-to-back
lever. Repair or replace worn or malfunctioning components.
If the seat does not move smoothly during adjustment, apply a small amount of
standard bearing grease (such as Shell Alvania
®
RL2 or equivalent) to the rails.
Ref. Part No. Qty. Description Measurement
1 0162359 1 Wiring harness, seat
2 0161998 1 Seat assembly
3 0174165 2 Spacer
4 0174181 2 Bolt 7/16-20
5 0161879 4 Strap—mounting
6 0174353 1 Clip
7 0161903 2 Washer
8 0161925 1 Cable clip
9 0174405 1 Grommet
10 0174406 2 Lock nut 7/16-20
11 0162006 1 Washer
12 0162023 2 Washer
