Webasto Mazda 6 User Manual

1313440A_EN
11
Mazda 6
Preparing heater unit
b = 910
c = 160
d = 750
Hose
A = 180° elbow, 18x18
Discard section
X
Cutting
coolant
hoses to
length
Push braided protection hoses onto hose B
and
D and cut to length.
Cut heat shrink plastic tubing to length.
1 25 mm long heat shrink plastic tubing [4x]
Preparing
coolant
hoses
1
27 mm dia. clamp
Premount-
ing hose C
Preparing bracket
1 Bracket
2 M6x40 bolt, 5 mm spacer sleeve, 20 mm
spacer sleeve, pin lock
3 M6x12 bolt, pin lock
Preparing
bracket
B
C
X
X
X
D
A
D
B
1
1
1 1
15
1C
16
1
3
2
