Mazda 6
1313440A_EN
5
Preliminary Work
WARNING!
- Open fuel tank cap, ventilate tank.
- Close the tank cap again.
- Disconnect the battery "earth" or "ground" connection.
- Depressurize the cooling system.
- Copy the factory number from the original type label to the duplicate type label.
- Remove years that do not apply from the duplicate label.
- Attach the duplicate label (type label) in the appropriate place.
- Completely remove the battery.
- Remove the air filter together with the intake hose.
- Remove the lower engine cover.
- Remove the vehicle underbody trim.
- Detach the wheel well trim on the right and left.
- Remove the bumper.
- Remove the rocker panel trim on the driver's side at the front.
- Remove the lower cover of the A-pillar trim in the driver's side footwell.
- Detach the BCM in the driver's side footwell.
- Remove the instrument panel trim below the steering wheel (only with Telestart T100 HTM).
- Remove the A/C control panel according to the manufacturer's instructions (only with automatic
air-conditioning).
Remove page 23 "Operating Instructions for End Customer" and insert with vehicle operating
instructions.
Heater unit installation location
1 Heater unit
Installation
location
1
1
