Webasto Mazda 6 User Manual

Mazda 6
1313440A_EN
8
All vehicles
Connection on 24-pin connector 0940-01A,
color black
1 from BCM 2.
Produce connections as shown in wiring
diagram.
Connector is located on rear side of BCM.
3 Red/white (rt/ws) wire of connector
4 Red (rt) wire from K3/87a
5 Black (sw) wire from K3/30
6 Route black (sw) wire 1² to A/C control panel
7 Red/white (rt/ws) wire of fan relay
Connec-
tion of fan
relay on
BCM
24-pin connector 0940-01A, color black 1
from BCM (on wire side)
2 Socket 1A, red/white (rt/ws) wire
BCM
connector
Automatic air-conditioning
Connection on connector B 3 of A/C control
panel, Pin 1G.
Produce connections as shown in wiring
diagram.
1 Black (sw) wire 1²
2 Insulate red/white (rt/ws) wire of 10 A air-
conditioner fuse and tie back
4 Red/white (rt/ws) wire of connector B, Pin 1G
Connect-
ing A/C
control
panel
24-pin connector 0740-201A, white 1 of A/C
control panel (on wire side)
2 Socket 1G, red/white (rt/ws) wire
Connector
KB
6
1
7
2 3
4
5
6
R
W
B
L
*
*
R
W
*
V
W
L
G
***
LR
**
R Y
* * * * *
B G G
R
1A
1B
1X
1W
B
GY
GY
LG
7
1
2
8
1 2
4 3
*
V
W
L
R
* * *
1A
1B
1X
1W
W
R
W
B
B
YG
V
L
R
L
W
W
B
G
WW
B
V
R
GY
B
LG
*
BR
R
Y
B
LG
P
B
1G
9
2
1
