Manual air conditioner
Connection on connector B 3 of A/C control
panel, Pin 1O.
Produce connections as shown in wiring
diagram.
1 Black (sw) wire 1²
2 Insulate red/white (rt/ws) wire of 10 A air-
conditioner fuse and tie back
4 Red/white (rt/ws) wire of connector B,
Pin 1O
Connect-
ing A/C
control
panel
24-pin connector 0740-101A, white 1 of A/C
control panel (on wire side)
2 Socket 1O, red/white (rt/ws) wire
Connector
KB
10
1 2
4
3
1A
1B1X
1W
W
R
W
Y
G
V
Y
P
B
B
LG
BR
RR
VL
RY
B L
V
* *
L
W W
*
B
R
LG
L
W
BL
B
GY
B
Y
R R
1O
11
2
1
