Webasto Mazda 6 User Manual

Mazda 6
1313440A_EN
7
Fan controller
Wiring
diagram
Webasto components Vehicle components Colors and symbols
Legend
HG Heater unit TT-C/E GM Fan motor rt red
X1
6-pin heater unit connector GRs Fan relay ws white
F3
Replace 25 A with 10 A fuse. GRr Fan controller sw black
Fb 40 A heater fuse
K3 Fan relay BCM Body Control Module
STA 24-pin connector of BCM,
black (0940-01A)
KB
Air-conditioning control panel
STB * 24-pin connector of KB with
automatic air-conditioning:
(0740-201A) Pin 1G
**
STB *
24-pin connector of KB with
manual air-conditioning:
(0740-101A) Pin 1O
**
X Cutting point
Wiring colors may vary.
Webasto
31
30
15
Mazda
F3
86
85 30
87a87
K3
HG
X1
4
BCM
St A
1A
Fb
+
-
GM
M
Fa
!
rt/ws
rt/ws sw
sw
rt
rt/ws
rt/ws
1²
1²
1²1²
1²
4²
4²
F-02
GRs
GRr
KB
1G/1O
St B
***

Webasto Mazda 6 Specifications

General

Brand	Webasto
Model	Mazda 6
Category	Water Heater
Language	English
