Service manual Safety 3
Symbols
The symbols illustrated on the following pages appear on the monitor or in this document.
Documentation symbols
WARNING Indicates conditions that could lead to illness, injury, or death.
Caution In this manual, indicates conditions that could damage equipment or other property.
Caution On the product, means “Consult accompanying documentation.”
Certification and operation labels
This device has been tested and certified by the
Canadian Standards Association International to
comply with applicable U.S. and Canadian medical
safety standards.
Urgent alarm notification (output to Nurse Call
system)
Patient connections are Type BF, and protected
against defibrillation.
Recycle used batteries properly and in accordance
with local regulations.
Do not dispose of batteries in refuse containers.
Australian Registered Importer Sealed lead-acid battery, 6V 4 Ah
Shipping, storing, and environment labels
Keep this end of the package or shipping crate up. Protect the monitor from exposure to rain.
Do not expose the monitor to relative humidity
above this limit.
Do not subject the monitor to altitudes outside
these limits.
Fragile contents—handle with care. Limit stacking to this number of units.
Do not expose the monitor to temperatures
outside these limits.
Monitor connector labels
Temperature Probe Cable Connector SpO
2
SpO
2
Sensor Cable Connector
RS232 Cable Connector AC Power Adapter Cable Connector
Nurse Call Cable Connector NIBP Hose Connector
To Next Page
