Handling the Printer
Xerox 8254E / 8264E Color Wide Format Printer
User Guide
4-77
5. After installing the media holder plates, make sure that they do not interfere with the media as it is
fed through the printer.
CAUTIONS:
• If a media jams when using the media holder plates, the plates may be deformed.
If the media holder plates are deformed:
• Do not remove the clogged media by force.
• Stop using the printer.
• Using the printer with deformed media plates may damage the grid roller or print heads. If you
need to replace media plates, contact your local Xerox dealer.
Note:
• If there is interference with the media as it is fed through the printer after the media
holder plates have been installed, the media holder plates should not be used
No. Name
1 Roll media
2 Media holder plate
3 Media loading position
4 Platen
