Product Overview
Xerox 8254E / 8264E Color Wide Format Printer
User Guide
2-2
Part Names and Functions
This section explains the name and function of each part.
8264E Printer Front Section
No. Name Function
1 Media loading lever Used for fixing or releasing media.
•Lower the lever to fix the media.
•Lower the lever more to fix the media more firmly. Used to improve the
accuracy of media feeding.
• Raise the lever to release the media.
2 Control panel Used to control operational condition settings and to view printer status
and various function settings.
Printer Control Panel
3 Front cover Used to prevent the user from coming into contact with the driving
mechanism during the printer operation. Opened and closed when media is
set or jammed. It is normally closed.
To Next Page
